Panasonic CU-3Z52TBE - CU-3 Z68 TBE Specifications

12
3.2 CU-3Z68TBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 2.0kW + 3.5kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
kW 6.8 (1.90 ~ 8.00)
Capacity
BTU/h 23200 (6480 ~ 27300)
Running Current A 8.40
Power Input W 1.86k (270 ~ 2.37k)
Electrical
Data
EER W/W 3.66 (7.04 ~ 3.38)
Annual Consumption kWh 298
Sound Pressure Level dB-A (H/L) 51 / -
Cooling Operation
Noise
Sound Power Level dB (H/L) 65 / -
kW 8.5 (3.30 ~ 10.40)
Capacity
BTU/h 29000 (11300 ~ 35500)
Running Current A 9.7
Power Input W 2.15k (620 ~ 2.86k)
Electrical
Data
COP W/W 3.95 (5.32 ~ 3.64)
Annual Consumption kWh 1733
Sound Pressure Level dB-A (H/L) 52 / -
Heating Operation
Noise
Sound Power Level dB (H/L) 66 / -
Maximum Current A 15.6
Starting Current A 9.70
Maximum Input Power W 3.55k
Capacity kW 4.45
Input Power W 2450
Extra Low Temperature
COP W/W 1.82
Height mm 795
Width mm 875 (+95)
Dimension
Depth mm 320
Net Weight kg 71
Pipe Length Range (1 room) m 3 ~ 25
Maximum Pipe Length (Total Room) m 60
Standard Length m 5
Height Difference m 15
Add. Gas Amount g/m 20
Piping
Pipe Length for Add. Gas m 30
Liquid Side mm (inch) 6.35 (1/4)
Refrigerant Pipe Diameter
Gas Side mm (inch) 9.52 (3/8)
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Compressor
Rated Output W 1.30k
Type Propeller Fan
Motor Type DC Motor (8-poles)
Fan Motor
Rated Output W 60
Fan Speed High (Cooling / Heating) RPM 600 / 680
