Panasonic CU-3Z52TBE - CU-4 Z68 TBE Specifications

14
3.3 CU-4Z68TBE
Item Unit OUTDOOR UNIT
Indoor Unit Combination 1.6kW + 1.6kW + 1.6kW + 2.0kW
Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit)
kW 6.80 (1.90 ~ 8.80)
Capacity
BTU/h 23200 (6480 ~ 30000)
Running Current A 7.00
Power Input W 1.55k (340 ~ 2.47k)
Electrical
Data
EER W/W 4.39 (5.59 ~ 3.56)
Annual Consumption kWh 298
Sound Pressure Level dB-A (H/L) 49 / -
Cooling Operation
Noise
Sound Power Level dB (H/L) 63 / -
kW 8.50 (3.00 ~ 10.60)
Capacity
BTU/h 29000 (36100 ~ 10200)
Running Current A 8.60
Power Input W 1.90k (580 ~ 2.68k)
Electrical
Data
COP W/W 4.47 (5.17 ~ 3.96)
Annual Consumption kWh 1933
Sound Pressure Level dB-A (H/L) 50 / -
Heating Operation
Noise
Sound Power Level dB (H/L) 64 / -
Maximum Current A 15.6
Maximum Input Power W 3.55k
Starting Current A 8.60
Capacity kW 4.45
Input Power W 2230
Extra Low Temperature
Cop W/W 2.00
Height mm 795
Width mm 875 (+95)
Dimension
Depth mm 320
Net Weight kg 72
Pipe Length Range (1 room) m 3 ~ 25
Maximum Pipe Length (Total Room) m 60
Standard Length m 5
Height Difference m 15
Add. Gas Amount g/m 20
Piping
Pipe Length for Add. Gas m 30
Liquid Side mm (inch) 6.35 (1/4)
Refrigerant Pipe Diameter
Gas Side mm (inch) 9.52 (3/8)
Type Hermetic Motor / Rotary
Motor Type Brushless (4-poles)
Compressor
Rated Output W 1.30k
Type Propeller Fan
Motor Type DC Motor (8-poles)
Fan Motor
Rated Output W 60
Fan Speed High (Cooling / Heating) RPM 600 / 620
