Panasonic CU-3Z52TBE - Printed Circuit Board Layouts; Main Printed Circuit Board

98
9. Printed Circuit Board
9.1 Main Printed Circuit Board
CN-TH1
CN-EV1
CN-HOT
CN-HT
CN-DIS
CN-TH2
CN-PSW1
CN-FM1
CN-HEAT
CN-EV2
CN-EV3
CN-EV4
CN-TH3
CN-TH4
CURRENT
TRANSFORME
R
(CT)
CN-DISP2
CN-DATA
POWER
TRANSISTOR
(IPM)
CN-NMODE
CN-DISP1
