19.2 Operation Characteristics (CU-3Z68TBE)
19.2.1 One Indoor Unit Operation
 Cooling Characteristic
[Condition] Room temperature: 27°C (DBT), 19°C (WBT)
Operation condition: High fan speed
Piping length: 5.0 m
Voltage: 230V, 50Hz
A) Indoor unit capacity: Cooling (2.0), CS-Z20TKEW
Outdoor Air Temperature (°C)
Indoor Discharge Ai
r
Temperature (°C)
-10-6 -2 2 6 10141822 2630 3438 4246
11.000
11.500
12.000
12.500
13.000
13.500
14.000
14.500
15.000
15.500
16.000
Outdoor Air Temperature (°C)
Current
(A)
-10-6-2 2 6 10141822263034384246
2.500
3.080
3.660
4.240
4.820
5.400
Outdoor Air Temperature (°C)
Gas Side Piping
Pressure (MPa)
0.700
0.730
0.760
0.790
0.820
0.850
0.880
0.910
0.940
0.970
1.000
-10-6 -2 2 6 10141822263034384246
