Panasonic CU-3Z52TBE - Page 288

288
SAFETY NO. DESCRIPTION & NAME Q’TY CU-3Z52TBE CU-3Z68TBE CU-4Z68TBE REMARK
1 CHASSIS ASSY 1 CWD52K1212 ← ←
2 SOUND PROOF BOARD 1 CWH151194 ← ←
3 FAN MOTOR BRACKET 1 CWD541127 ← ←
4 SCREW-BRACKET FAN MOTOR 3 CWH551217 ← ←
5 CONDENSER COMPLETE 1 CWB32C2680 ← ACXB32C08970
6 FAN MOTOR, DC 60W 3PH 1 EHDS80C60AC ← ← O
7 SCREW-FAN MOTOR MOUNT 4 CWH551323 ← ←
8 PROPELLER FAN ASSY 1 CWH00K1006 ← ←
9 NUT 1 CWH561092 ← ←
10 COMPRESSOR 1 9KD184XAA21 ← ← O
11 PACKING 3 CWB81043 ← ←
12 BUSHING-COMPRESSOR MOUNT 3 CWH50055 ← ←
13 NUT-COMPRESSOR MOUNT 3 CWH561049 ← ←
14 CRANKCASE HEATER 1 CWA341047 ← ←
15 TUBE ASSY (CAPILLARY TUBE) 1 CWT01C4955 ← ←
16 ACCUMULATOR 1 CWB131050 ← ←
17 3-WAY VALVE 1 CWB011601 ← ← O
18 3-WAY VALVE 1 CWB011602 ← ← O
19 HOLDER COUPLING 1 CWH351258 ← ←
20 STRAINER 1 CWB11061 ← ←
21 STRAINER 3/4 CWB111024 ← ←
22 EXPANSION VALVE 3/4 CWB051029 ← ← O
23 4-WAYS VALVE 1 CWB001026J ← ← O
24 DISCHARGE MUFFLER 2 ACXB12-00650 ← ←
25 HEATING PRESSURE SWITCH 1 CWA101013 ← ←
26 FLARE NUT (1/4) 3/4 CWT251030 ← ←
27 FLARE NUT (3/8) 3/4 CWT251031 ← ←
28 SOUND PROOF MATERIAL 1 CWG302246 ← ←
29 SOUND PROOR MATERIAL 1 CWG302520 ← ←
30 SOUND PROOR MATERIAL 1 CWG302521 ← ←
31 SOUND PROOR MATERIAL 1 CWG302522 ← ←
32 SENSOR COMPLETE - (CN-DIS) 1 CWA50C2515 ← ← O
33 V-COIL COMPLETE (4-WAY VALVE) 1 CWA43C2169J ← ← O
34 V-COIL COMPLETE (E/VALVE-WHITE) 1 CWA43C2334 ← ← O
35
V-COIL COMPLETE (E/VALVE-
YELLOW)
1 CWA43C2335 ← ← O
36 V-COIL COMPLETE (E/VALVE-BLUE) 1 CWA43C2336 ← ← O
37 V-COIL COMPLETE (E/VALVE-RED) 1 - - CWA43C2338 O
38 SENSOR-COMPLETE - DEF (CN-TH2) 1 CWA50C2625 ← ← O
39
SENSOR-COMPLETE - OUTLET TEMP
SENSOR
1 CWA50C2517 ← ← O
40 SENSOR-COMPLETE (CN-TH4) 1 CWA50C2620 ← CWA50C2616 O
41 SENSOR-COMPLETE (CN-TH3) 1 CWA50C2622 ← CWA50C2617 O
43 ELECTRONIC CONTROLLER 1 ACXA73C21000R ACXA73C21010R ACXA73C21020R O
44
ELECT CONTROLLER – NOISE
FILTER
1 ACXA73-07870 ← ← O
45 ELECT CONTROLLER (DISPLAY) 1 CWA745292 ← ← O
47 REACTOR 2 G0C403J00001 ← ← O
48 TERMINAL BOARD ASSY 1 CWA28K1195 ← ← O
