Panasonic CU-NE9NKE - Page 111

111
REF.
NO.
PART NAME & DESCRIPTION QTY CS-WE9NKE CS-WE12NKE REMARK
1 CHASSY COMPLETE 1 CWD50C1731 ←
2 FAN MOTOR 1 ARW7666ACCB ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1135 ←
4 BEARING ASS'Y 1 CWH64K1010 ←
5 GENERATOR COMPLETE 1 CWH94C0048 ←
6 EVAPORATOR COMPLETE 1 CWB30C3968 CWB30C3966
7 FLARE NUT (LIQUID) 1 CWT251030 ←
8 FLARE NUT (GAS) 1 CWT251031 ←
9 HOLDER SENSOR 1 CWH32143 ←
9a HOLDER SENSOR 1 CWH321085 ←
10 BACK COVER CHASSIS 1 CWD933463A ←
11 DISCHARGE GRILLE COMPLETE 1 CWE20C3308 ←
12 VERTICAL VANE 8 CWE241389 ←
13 VERTICAL VANE 2 CWE241409 ←
14 CONNECTING BAR 2 CWE261272 ←
18 FULCRUM 1 CWH621139 ←
19 HORIZONTAL VANE COMPLETE 1 CWE24C1431 ←
20 HORIZONTAL VANE COMPLETE 1 CWE24C1421 ←
21 AIR SWING MOTOR 1 CWA981241 ← O
22 AIR SWING MOTOR 1 CWA981299 ← O
23 CAP - DRAIN TRAY 1 CWH521259 ←
24 SENSOR COMPLETE 1 CWA50C2663 ←
25 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6848 CWA73C6849 O
26 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000002 ← O
27 CONTROL BOARD CASING 1 CWH102456 ←
28 CONTROL BOARD TOP COVER 1 CWH131531 ←
29 CONTROL BOARD FRONT COVER CO. 1 CWH13C1286 ←
30 TERMINAL BOARD COMPLETE 1 CWA28C2364 ←
31 INDICATOR COMPLETE 1 CWE39C1231 ←
32 INDICATOR HOLDER 1 CWD933466 ←
33 FRONT GRILLE COMPLETE 1 CWE11C5435 ← O
34 GRILLE DOOR COMPLETE 1 CWE14C1102 ←
35 INTAKE GRILLE COMPLETE 1 CWE22K1611 ← O
36 DECORATION BASE ASS'Y (L) 1 CWE35K1145 ←
37 DECORATION BASE ASS'Y (R) 1 CWE35C1192 ←
38 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←
39 AIR FILTER 2 CWD001326 ←
40 FLEXIBLE PIPE 1 CWH851173 ←
41 REMOTE CONTROL COMPLETE 1 CWA75C4153 ← O
42 INSTALLATION PLATE 1 CWH361134 ←
43 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
44 OPERATING INSTRUCTION 1 CWF568749 ←
45 INSTALLATION INSTRUCTION 1 CWF615521 ←
46 INSTALLATION INSTRUCTION 1 CWF615522 ←
47 INSTALLATION INSTRUCTION 1 CWF615523 ←
48 INSTALLATION INSTRUCTION 1 CWF615524 ←
49 INSTALLATION INSTRUCTION 1 CWF615525 ←
50 BAG 1 CWG861515 ←
