Airflow Direction Auto-control
Airflow direction manual control
7.6. Airflow Direction Control
•
• •
•
When set at airflow direction auto-control with remote controller, the louver swings up and down as shown in the table below.
•
• •
•
The louver does not swing when the indoor fan stops during operation.
•
• •
•
When stop the unit with remote controller,the discharge vent is closed with the louver.
•
• •
•
When temperature of indoor heat exchanger reaches 38°C during heating mode operation, if temperature falls to 35°C, airflow
direction will change from the lower limit to horizontal.
The left and right airflow direction louver can be adjusted manually.
•
• •
•
When the airflow direction set button is pressed,the automatic airflow is released and the airflow direction louver moves up and
down as shown in thetable below. The louver can be stopped by releasing the button at the desired position.
•
• •
•
When the remote controller is used to stop the operation,the discharge vent is closed with airflow direction louver.
Notes:
In heating mode operation
1. Airflow direction automatic control:
The airflow direction is automatically adjusted to horizontal direction when the temperature of indoor heat exchanger is low
and it will be automatically adjusted downward while the indoor temperature rises.
2. Airflow direction manual control:
The airflow direction is automatically adjusted to horizontal direction temperature of indoor heat exchanger is low. While
temperature of indoor heat exchanger rises, the airflow direction is automatically adjusted to the place set by the remote
controller.
In cooling or soft dry mode operation
If the compressor continues to operate for 60 minutes, and the louver direction is at No 4 or No 5,the fan speed is below Med,
the intake air temperature is below 29°C and continues to change between ±2°C for 30 minutes, the louver direction will be at
No 2 in order to prevent dew around the discharge vent.
24
CS-SA9CKP CU-SA9CKP5 / CS-SA12CKP CU-SA12CKP5
