Panasonic CU-SA9CKP5 - Page 48

3. Remove the fan motor.
Loosen the fan motor securing screw at the junction of
the cross fan. (see
Fig 5
)
Remove the special tab, and pull the fan motor out.
(see
Fig 6
,
Fig 7
)
Fig 5
Fig 6
Fig 7
48
CS-SA9CKP CU-SA9CKP5 / CS-SA12CKP CU-SA12CKP5
