16 Replacement Parts List
<Model: CS-V18CKE CS-V24CKE>
REF. NO. PART NAME & DESCRIPTION QTY. CS-V18CKE CS-V24CKE REMARKS
1 CHASSY COMPLETE 1 CWD50C1293
←
←←
←
2 FAN MOTOR 1 CWA981056
←
←←
←
0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010
←
←←
←
4 SCREW - CROSS FLOW FAN 1 CWH4580304
←
←←
←
5 BEARING ASS’Y 1 CWH64K007
←
←←
←
6 EVAPORATOR 1 CWB30C1375 CWB30C1377
7 FLARE NUT 1 CWT25086 (1/4”)
←
←←
←
8 FLARE NUT 1 CWT25096 (1/2”) CWT251016
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
←
←←
←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2254
←
←←
←
11 VERTICAL VANE 15 CWE241088
←
←←
←
12 CONNECTING BAR 1 CWE261025
←
←←
←
13 AIR SWING MOTOR 1 CWA98260
←
←←
←
0
14 AIR SWING MOTOR 1 CWA981041
←
←←
←
0
15 LEAD WIRE - AIR SWING MOTOR 2 CWA67C3731
←
←←
←
16 HORIZONTAL VANE 1 CWE241136
←
←←
←
17 CAP - DRAIN TRAY 1 CWH52C1001
←
←←
←
18 BACK COVER CHASSIS 1 CWD932162
←
←←
←
19 CONTROL BOARD 1 CWH102103
←
←←
←
20 TERMINAL BOARD COMPLETE 1 CWA28C2153 CWA28C2094 0
21 POWER SUPPLY CORD 1 CWA20C2348 CWA20C2349
22 ELECTRONIC CONTROLLER - MAIN 1 CWA743141 CWA743139 0
23 ELECTRONIC CONTROLLER - POWER 1 CWA743348
←
←←
←
0
25 P.C.B. RECEIVER 1 CWA742724
←
←←
←
0
26 INDICATOR COMPLETE 1 CWE39C1089
←
←←
←
0
27 LEAD WIRE - INDICATOR 1 CWA67C4947
←
←←
←
28 INDICATOR HOLDER 1 CWD932163
←
←←
←
29 SENSOR COMPLETE 1 CWA50C2122
←
←←
←
0
30 CONTROL BOARD TOP COVER 1 CWH131091
←
←←
←
31 CONTROL BOARD FRONT COVER 1 CWH131090
←
←←
←
32 REMOTE CONTROL COMPLETE 1 CWA75C2422
←
←←
←
0
33 FRONT GRILLE COMPLETE 1 CWE11C2967
←
←←
←
0
34 INTAKE GRILLE COMPLETE 1 CWE22C1105
←
←←
←
35 GRILLE DOOR 1 CWE141033
←
←←
←
36 CONTROL PANEL 1 CWE312274
←
←←
←
37 DECORATION BASE (R) 1 CWE351067
←
←←
←
38 DECORATION BASE (L) 1 CWE351068
←
←←
←
39 AIR FILTER 2 CWD001049
←
←←
←
40 SCREW - FRONT GRILLE 4 XTT4+16C
←
←←
←
41 CAP - FRONT GRILLE 3 CWH521062
←
←←
←
42 DRAIN HOSE 1 CWH851044
←
←←
←
43 AIR PURIFYING FILTER 1 CWMD00C0001
←
←←
←
0
44 TRIPLE DEODORIZING FILTER 1 CWMD00C0004
←
←←
←
0
45 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
←
←←
←
46 INSTALLATION PLATE 1 CWH36K1007
←
←←
←
47 FULCRUM 2 CWH621013
←
←←
←
48 ELECTRONIC CONTROLLER - IONIZER 1 CWA743099
←
←←
←
0
49 CASING - IONIZER 1 CWD932228
←
←←
←
50 ION - GENERATOR 1 CWH94C0001
←
←←
←
(Note)
•
• •
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
• •
•
“0” marked parts are recommended to be kept in stock.
68
CS-V18CKE CU-V18CKE / CS-V24CKE CU-V24CKE
