Panasonic CU-V18CKE - Replacement Parts List

18 Replacement Parts List
<Model: CU-V18CKE CU-V24CKE>
REF. NO. PART NAME & DESCRIPTION QTY. CU-V18CKE CU-V24CKE REMARKS
1 CHASSY ASS’Y 1 CWD50K515B CWD50K514B
2 SOUND PROOF BOARD 1 CWH15223
←
←←
←
3 FAN MOTOR BRACKET 1 CWD54238 CWD54237
4 SCREW - FAN MOTOR BRACKET 4 CWH55027
←
←←
←
5 FAN MOTOR 1 CWA921178 CWA921078 0
6 SCREW - FAN MOTOR MOUNT 4 CWH55252
←
←←
←
7 PROPELLER FAN ASS’Y 1 CWH00K087 CWH00K1001
8 NUT - PROPELLER FAN 1 CWH56053 CWH56060
9 COMPRESSOR 1 5KS205DAA 5JS315DAA 0
10 PACKING 1 CWB81047
←
←←
←
11 ANTI - VIBRATION BUSHING 3 CWH50055
←
←←
←
12 NUT - COMPRESSOR MOUNT 3 CWH4582065
←
←←
←
14 CONDENSER 1 CWB32C1201R CWB32C1299
15 HOLDER COUPLING ASS’Y 1 CWH35K029B CWH35K030B
16 2-WAY VALVE (LIQUID) 1 CWB021167
←
←←
←
0
17 3-WAY VALVE (GAS) 1 CWB011155 CWB011156 0
19 TERMINAL COVER 1 CWH171012
←
←←
←
20 NUT - TERMINAL COVER 1 CWH7080300
←
←←
←
21 CONTROL BOARD ASS’Y 1 CWH10K1019
←
←←
←
22 CAPACITOR - FAN MOTOR (3.5µF, 450VAC) 1 F0GAH355A002
←
←←
←
0
23 CAPACITOR - COMPRESSOR 1 DS371506CPNA
(50µF, 370VAC)
DS371456CPNA
(45µF, 370VAC)
0
25 HOLDER CAPACITOR 1 CWH30060
←
←←
←
26 THERMOSTAT 1 CWA15129
←
←←
←
27 TERMINAL BOARD ASS’Y 1 CWA28K1020
←
←←
←
28 FUSE 1 - -
29 HOLDER - SENSOR 1 CWH32002
←
←←
←
31 CABINET FRONT PLATE 1 CWE06K034B
←
←←
←
32 CABINET REAR PLATE 1 CWE02096B
←
←←
←
33 CABINET FRONT PLATE 1 CWE06075B
←
←←
←
34 CABINET SIDE PLATE 1 CWE04111B
←
←←
←
35 CABINET TOP PLATE 1 CWE03101B
←
←←
←
36 CONTROL BOARD COVER 1 CWH13336A
←
←←
←
37 HANDLE 2 CWE16000E
←
←←
←
43 TUBE ASS’Y (RECEIVER) 1 CWT01C2437
←
←←
←
44 CAPILLARY TUBE 1 CWB15315 CWB152107
45 DRYER 1 CWB101002
←
←←
←
42 SUPPORTER PLATE-COM 1 CWD90830
←
←←
←
38 OPERATION INSTRUCTIONS 1 CWF564064
←
←←
←
46 OPERATION INSTRUCTIONS 1 CWF564065
←
←←
←
47 OPERATION INSTRUCTIONS 1 CWF564066
←
←←
←
39 INSTALLATION INSTRUCTIONS 1 CWF612497
←
←←
←
40 INSTALLATION INSTRUCTIONS 1 CWF612498
←
←←
←
41 INSTALLATION INSTRUCTIONS 1 CWF612499
←
←←
←
(Note)
•
• •
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
• •
•
“0” marked parts are recommended to be kept in stock.
