35
1. Release fixing screws on both side, disassembly the fixing board from
evaporator on the left side and pull out the whole evaporator.
2. Loose the fixing screw of the cross flow fan.
3. After removing the bearing, indoor fan can be taken out from the left side
4. Lift up the indoor fan slightly, and then pull the fan motor out.
Removal Procedure for Cross Flow Fan
Fixing Screw
Bearing
Fan motor
To Next Page
