Panasonic CU-YC12MKV - Specification; CS;CU-YC9 MKV, CS;CU-YC12 MKV Specifications

5
2. Specification
2.1 CS/CU-YC9MKV, CS/CU-YC12MKV
Indoor CS-YC9MKV CS-YC12MKV
Model
Outdoor CU-YC9MKV CU-YC12MKV
Phase, Hz Single, 60 Single, 60
Power Supply
V 220 220
kW 2.64 3.52
BTU/h 9000 12000
Capacity
kJ/h 2270 3027
Running Current A 4.30 5.50
Input Power W 900 1180
W/W 2.93 2.98
EER
Btu/hW 10.00 10.17
Power Factor % 95 97
Indoor Noise (H / L ) dB-A 37 / 30 / 39 / 33 /
Cooling
Outdoor Noise (H / L) dB-A 49 / - 49 / -
Max Current (A) / Max Input Power (W) 5.90 / 1.130k 7.40 / 1.450k
Starting Current (A) 25.0 34.0
Type Hermetic Motor Hermetic Motor
Motor Type Induction (2 poles) Induction (2 poles)
Compressor
Output Power W 750 1.100k
Type Cross-flow fan Cross-flow fan
Material AS AS
Motor Type Induction (4 poles) Induction (4 poles)
Input Power W - -
Output Power W 20 20
Lo rpm 780 850
Me rpm 880 960
Indoor Fan
Hi rpm 1010 1060
Type Propeller Propeller
Material PP PP
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W - -
Output Power W 28 28
Outdoor Fan
Speed Hi rpm 840 880
Moisture Removal L/h (Pt/h) 1.5 (2.6) 2.0 (3.4)
Lo m
3
/min (ft
3
/m) 8.9 (315) 9.8 (347)
Me m
3
/min (ft
3
/m) 10.1 (355) 11.6 (392)
Indoor Airflow
Hi m
3
/min (ft
3
/m) 11.6 (408) 12.3 (433)
Outdoor
Airflow
Hi m
3
/min (ft
3
/m) 26.8 (948) 26.8 (948)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
ATMOS M60 OR SUNISO 4GDID
（290）
ATMOS NM56 OR SUNISO 4GDID (350)
Refrigeration
Cycle
Refrigerant
Type
g (oz) R22, 550 (19.3) R22, 820 (28.9)
Height(I/D /
O/D)
mm (inch) 283 (11-5/32) 530(20-7/8) 283 (11-5/32) 530 (20-7/8)
Width (I/D / O/D) mm (inch) 803 (31-5/8) 650(25-19/32) 803 (31-5/8) 650 (25-19/32)
Dimension
Depth (I/D /
O/D)
mm (inch) 214 (8-7/16) 230 (9-1/16) 214 (8-7/16) 230 (9-1/16)
