41
REF.
NO.
PART NAME & DESCRIPTION QTY. CU-YC12MKV CU-YC12MKV-6 CU-YC12MKV-7
Remark
1
CHASSIS ASS'Y 1 CWD52K1216A CWD52K1216A CWD52K1216A
2
FAN MOTOR BRACKET 1 CWD541097 CWD541097 CWD541097
3
SCREW-FAN MOTOR BRACKET 2 CWH551148A CWH551148A CWH551148A
4
FAN MOTOR 1 CWA951777 CWA951777 CWA951777
O
5
SCREW-FAN MOTOR MOUNT 3 CWH55406J CWH55406J CWH55406J
6
PROPELLER FAN ASS'Y 1 CWH03K1025 CWH03K1025 CWH03K1025
7
NUT-PROPELLER FAN 1 CWH561036J CWH561036J CWH561036J
8
COMPRESSOR 1 CWB092578 CWB092578 CWB092578
O
9
ANTI-VIBRATION BUSHING 3 CWH501022 CWH501022 CWH501022
10
NUT-COMPRESSOR MOUNT 3 CWH561047A CWH561047A CWH561047A
11
CONDENSER 1 CWB32C3088 CWB32C3088 CWB32C3092
12
HOLDER COUPLING ASS'Y 1 CWH351064A CWH351064A CWH351064A
13
2-WAY VALVE 1 CWB021260 CWB021260 CWB021260
O
14
3-WAY VALVE 1 CWB011323 CWB011323 CWB011323
O
15
NUT FOR TERMIANL COVER 1 CW7080300J CW7080300J CW7080300J
16
SOUND PROOF BOARD 1 CWH151080 CWH151080 CWH151080
17
SOUND PROOF MATERIAL 1
CWG302554/
CWG302556
CWG302554/
CWG302556
CWG302554/
CWG302556
18
TUBE ASS'Y(CAPILLARY) 1 CWT01C5254 CWT01C5254 CWT01C5477
19
CAPILLARY 1 1 CWB15380 CWB15380 CWB15308
23
TOP PLATE 1 CWE031044A CWE031044A CWE031044A
24
CABINET FRONT PLATE 1 CWE06K1061 CWE06K1061 CWE06K1061
25
CABINET SIDE PLATE (R) 1 CWE041125A CWE041125A CWE041125A
26
CABINET SIDE PLATE (L) 1 CWE041124A CWE041124A CWE041124A
27
CONTROL BOX COVER(OUT) 1 CWH131223 CWH131223 CWH131223
28
CAPACITOR-COMP. 1 DS371306CPXC DS371306CPXC DS371306CPXC
O
29
CAPACITOR-HOLDER 1 CWH301037 CWH301037 CWH301037
30
CAPACITOR-FM 1 DS401205XPQC CWDS401205XPQC DS401205XPQC
O
31
TERMINAL BOARD ASS'Y 1 CWA28K1176 CWA28K1176 CWA28K1176
(Note)
z All parts are supplied from PHAAG, China.
z “O” marked parts are recommended to be kept in stock
