8
Weight Net (I/D / O/D) kg (lb) 8.0 (18) 21 (46) 8.0 (18) 26 (57)
Pipe Diameter (Liquid /
Gas)
mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~15 (49.2) 3 (9.8) ~ 15(49.2)
I/D & O/D Height different m (ft) 5.0 (16.4) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 5.0 (16.4) 5.0 (16.4)
Inner Diameter mm 16 16
Drain Hose
Length mm 500 500
Fin Material Pre coated Pre coated
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI
2 x 16 x 19 2 x 16 x 19
Indoor Heat
Exchanger
Size (W x H x L) mm 610 x 336 x 25.4 610 x 315 x 25.4
Fin Material Bear Fin Bear Fin
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI
1 x 24 x 18 2 x 24 x 18
Outdoor
Heat
Exchanger
Size (W x H xD) mm 570.7 x504.0 x 12.7 565.2(545.3) x 504.0 x 12.7
Material P.P.HONEY COMB P.P.HONEY COMB
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat - -
Protection Device - -
DRY BULB WET BULB DRY BULB WET BULB
Maximum 32 23 32 23
Indoor Operation Range
Minimum 16 11 16 11
Maximum 43 26 43 26
Outdoor Operation Range
Minimum 16 11 16 11
2. Cooling capacities are based on indoor temperature of 27°C DRY BULB (80.6°F DRY BULB), 19.0°C WET BULB (66°F WET BULB) and
outdoor air temperature of 35°C DRY BULB (95°F DRY BULB), 24°C WET BULB (75.2°F WET BULB)
