10
VQT2J39
STEP 2 Channel reception settings and TV aspect settings
1 Turn on the television and select the
appropriate AV input to suit the
connections to this unit.
2 Press [Í] to turn the unit on.
When connecting to a television that has the VIERA Link or Q
Link functions (> 34), downloading from the television starts.
You can download the tuning positions from the television for
the channels in this unit’s channel coverage.
The unit will search for the terrestrial digital channels. TV
channels will be located and stored ready for use.
This takes 5 minutes.
The features of the Power Save in Standby function when
the unit is in standby mode are as below.
§
1
“Unit’s Display” is set to “Automatic” in the Setup menu.
(
>
62)
§2
It is possible to startup and start recording within several
seconds.
Depending on the type of TV or the connected terminal, it
may take time to display the screen.
§
3
When “RF OUT ( Aerial Signal )” is set to “Off” in the
Setup menu (
>
65)
If the TV aspect setting screen appears on the
television.
Press [3, 4] to select the TV aspect and press [OK].
16:9:
When connected to a 16:9 widescreen television
Pan & Scan:
When connected to a 4:3 aspect television,
side picture is trimmed for 16:9 picture
(> 78).
Letterbox:
When connected to a 4:3 aspect television.
16:9 picture is shown in the letterbox style
(> 78).
When television picture appears, set up is complete.
To stop partway
Press [RETURN ].
If the Country setting menu appears on the television.
Press [3, 4] to select the country and press [OK].
DVB Auto Setup starts.
3 Press [3, 4] to select “On”, “Off” or
“On Timer” and press [OK] when the
“Power Save in Standby” setting
menu appears.
On: It will go into the Power Save in Standby mode
when the unit is in standby mode.
Off: It is possible to start quickly from the standby mode.
(Quick Start mode)
On Timer:
Press [3, 4, 2, 1] to set the start and stop time
and then press [OK].
“Power Save in Standby” is set to activate during
the setting time period.
MANUAL SKIP
STOP
PAUSE
PLAY/x1.3
INPUT
SELECT
0
9
8
7
6
54
3
2
1
CH
CH
PAGE
SLOW/SEARCH
VOL
AV
DRIVE
SELECT
TV
STATUS
EXIT
OPTION
RETURN
DELETE
OK
D
I
R
E
C
T
N
A
V
I
G
A
T
O
R
F
U
N
C
T
I
O
N
M
E
N
U
P
R
O
G
/
C
H
E
C
K
CHAPTER
DISPLAY
PAUSE LIVE TV
SKIP
OK
,,,
OK
RETURN
DVB Auto Setup
Scan CH 5 69
CH
Quality
Channel Name Type
ABC
ABC 2
1
2
TV
Data
9
9
Power Save in Standby
Power Save On
To
6
:00
From
0
:00
Saves standby power consumption
b di bli Q i k S f i d
Power Save in Standby Activated (On/
On Timer)
§1
Deactivated
(Off)
Power consumption
Approx. 0.3 W
§3
Approx. 11 W
Startup time Not Quick
Quick
§2
Watching the picture
(e.g. Pay TV) from the
device connected to AV2
Cannot do Can do
If the clock setting menu appears
Set the clock manually (> 64).
To confirm that stations have been tuned
correctly (> 60)
To restart set up (> 59)
The auto setup screens may be displayed in French, Italian or
Spanish. After completing step 3, change the on-screen
display to English in the following steps.
1 Press [FUNCTION MENU].
2 Press [3, 4] to select
“Autres” (French)
“Altre funzioni” (Italian)
“Otras” (Spanish)
and press [OK].
3 Press [3, 4] to select
“Configuration” (French)
“Impostazioni” (Italian)
“Configuración” (Spanish)
and press [OK].
4 Press [3, 4] to select
“Affichage” (French)
“Display” (Italian)
“Display” (Spanish)
and press [1].
5 Press [3, 4] to select
“Langue” (French)
“Lingua” (Italian)
“Idioma” (Spanish)
and press [OK].
6 Press [3, 4] to select “English” and press [OK].
7 Press [EXIT].
