14
VQT2J39
Regarding DivX files, Music files and still pictures (JPEG)
DivX
MP3
If there is a large amount of still picture data etc. within a MP3 file,
play may not be possible.
Still pictures (JPEG
§3
)
§1
[USB] DivX VOD contents cannot be played back.
§2
Total number of recognizable file including MP3, JPEG, DivX and
other types of files is 4000.
§3
It may take a few moments for still pictures to display.
§4
When there are many files and/or folders, some files may not
display or be playable.
[-R] [-R]DL] [CD]
Compatible formats:
ISO9660 level 1 or 2 (except for extended formats) and Joliet
This unit is compatible with multi-session/border (except for DVD-
R DL), but reading or play of the disc may take time if there are a
lot of sessions.
Operation may take time to complete when there are many files
(tracks) and/or folders (groups or albums) and some files (tracks)
may not display or be playable.
English alphabet and Arabic numerals are displayed correctly.
Other characters may not be displayed correctly.
The display order on this unit may differ from how the order is
displayed on a computer.
Depending on how you create the disc (writing software), files
(tracks) and folders (groups or albums) may not play in the order
you numbered them.
This unit is not compatible with packet-write format.
Depending on the recording conditions, the disc may not be
played.
[HDD] [RAM]
Compatible formats: DCF
§5
compliant (Content recorded on a
digital camera, etc.)
§5
Design rule for Camera File system: unified standard established
by Japan Electronics and Information Technology Industries
Association (JEITA).
Structure of folders displayed by this unit
You can play Music files (MP3) and still pictures (JPEG) on this
unit by making folders as shown below. However depending on
the method of writing data (writing software), play may not be in
the order you numbered the folders.
Playable
media
[-R] [-R]DL] [CD] [USB]
§1
File format DivX
Files must have the extension “.DIVX”, “.divx”,
“.AVI” or “.avi”.
Number of
folders
Maximum number of folders recognizable: 300
folders
(including the root folder)
Number of
files
Maximum number of files recognizable
§2
: 200 files
Support
version
Certified to the DivX Home Theater Profile V3.0.
Video
Number of stream: Up to 1
Codec: DIV3, DIV4, DIVX, DV50
16 k 16 to 720 k 576 (25 fps)
16 k 16 to 720 k 480 (30 fps)
Aspect Ratio: 10:11, 40:33, 16:11, 12:11, 1:1
Audio
Number of stream: Up to 8
Format: MP3, MPEG, Dolby Digital
Multi channel: Dolby Digital is possible. MPEG
multi is 2 ch conversion.
Bitrate: 16 kbps to 320 kbps (MP3/MPEG),
32 kbps to 448 kbps (Dolby Digital)
Sampling frequency.: 16 kHz/22.05 kHz/24 kHz/
32 kHz/44.1 kHz/48 kHz (MP3/MPEG)/32 kHz/
44.1 kHz/48 kHz (Dolby Digital)
Playable
media
[HDD] [-R] [-R]DL] [CD] [USB]
File format MP3
Files must have the extension “.mp3” or “.MP3”.
Number of
folders
(groups or
albums)
Maximum number of folders (groups or albums)
recognizable: 300 folders (groups or albums)
(including the root folder)
Number of
files (tracks)
Maximum number of files (tracks) recognizable
§2
:
3000 files (tracks)
Bit rates 32 kbps to 320 kbps
Sampling
frequency
16 kHz/22.05 kHz/24 kHz/32 kHz/44.1 kHz/48 kHz
ID3 tags compatible ([HDD] [USB])
Playable
media
[HDD] [RAM] [-R] [-R]DL] [CD] [USB]
File format JPEG
Files must have the extension “.jpg” or “.JPG”.
Compatible
pixels
Between 34k34 and 6400k6400
(Sub sampling is 4:2:2 or 4:2:0)
Number of
folders
§4
[-R] [-R]DL] [CD] [USB] Maximum number of folders
recognizable: 300 folders
[HDD] [RAM] This unit can handle a maximum of 300
folders
Number of
files
§4
[-R] [-R]DL] [CD] [USB] Maximum number of files
recognizable
§2
: 3000 files
[HDD] [RAM] This unit can handle a maximum of 3000
files
MOTION
JPEG
PROGRESSIVE
JPEG
Not supported
Structure of MP3
folders
[-R] [-R]DL] [CD] [USB]
Prefix with 3-digit
numbers in the order
you want to play them.
Structures of still
picture folders
[-R] [-R]DL] [CD] [USB]
Files inside a folder are
displayed in the order
they were updated or
taken.
[RAM]
Folders can be created on
other equipment.
§
These folders cannot be
selected as a copying
destination.
If a folder name or file
name has been input using
other equipment, the name
may not be displayed
properly or you may not be
able to play or edit the
data.
002
001
001
001.mp3
002.mp3
003.mp3
003
001.mp3
002.mp3
003.mp3
001.mp3
002.mp3
003.mp3
004.mp3
Root
Order of
play
(folder=group)
(file=track)
XXXX

.
jpg
DCIM
XXXXX
Root
Order of
play
002 Folder
003 Folder
004 Folder
DCIM
JPEG
XXXX

.jpg
XXXX

.jpg
XXXXX
XXXXX
DCIM
XXXX

.jpg
Root
DMREX773EC-VQT2J39_eng.book 14 ページ 2010年1月14日 木曜日 午後1時31分
