13
• Step 4. Display the "INITIAL SETTINGS" menu:
* If the unit is other than PROGRAM AE
mode, it does not display the initial settings menu.
While keep pressing MENU/SET
and “ RIGHT of Cursor button" simultaneously, turn the Power off.
The "INITIAL SETTINGS" menu is displayed.
There are two kinds of "INITIAL SETTINGS" menu form as follows:
[CASE 1. After replacing MAIN P.C.B.]
There are three kinds of menu from as follows:
[Except for "DMC-TZ80EG, EF, EB, EP and TZ81EG" models : (SEP0684AC is used as a Main P.C.B.)]
When Main P.C.B. has just been replaced, all of the model suffix are displayed as follows. (Three pages in total)
[Only for "DMC-TZ80EG, EF, EB, EP and TZ81" models : (SEP0684AD is used as a Main P.C.B.)]
When Main P.C.B. has just been replaced, only 5 model suffix are displayed as follows. (Two pages in total)
To display the "TZ81" model suffix, press the DELETE
button.
To Next Page
