Service
Number
Contents Contents of Indication on
minute
Contents of Indication on
second
Remarks
2 Indication for
the inner data
of IC6001
Mechanism position
(Real time)
0L: EJECT position
02: DOWN position
03: RREW position
04: LOAD position
05: REV position
06: PLAY position
07:POFF position
08: STOP_R position
09: STOP_F position
- : FF/REW position
- : Intermediate between
each positions
Ordering for the Motors
(Real time)
0*, 2*: CYL off,
CAPoff
1*: CYL off,
CAP on (fwd)
3*:CYL off,
CAP on (rev)
8*, A*: CYL on,
CAPoff
9*: CYL on,
CAP on (fwd)
B*:CYL on,
CAP on (rev)
*0: Motor off
*1: Loading
*2: Unloading
*3: Break (Load + Unload)
There are next conditions
in this mode for enable the
mechanism operations
without a cassette tape.
The starting / finishing
edges are not detected.
The reel lockis not
detected
The tape and the
positions are not detected.
, And so on.
Press the EJET key for
over 3 seconds in this
mode, and then the VCR is
shifted into the special
modes, such as PG
Adjustment, Model Code
Setting,and so on.
The orders for the motors
are as follows.
Bit 7: CYL ON/OFF
Bit 6: ------------------
Bit 5: CAP FWD/REV
Bit 4: CAP ON/OFF
Bit 3: ------------------
Bit2: ------------------
Bit 1: UNLOADING(H)
Bit 0: LOADING(H)
