Error
No.
Reason Supplementary Data
Data 1 Data 2 Data 3 Data 4
21 NG2 in the PG Shifter Automatic
Adjustment
(The vertical sync signal is lacked
while over 5 seconds on the alignment
tape.)
VHS mode - Process
No.
-
22 NG3 in the PG Shifter Automatic
Adjustment
(The installing position of Heads to the
cylinder is our of specification.)
VHS mode - Process
No.
-
23 NG4 in the PG Shifter Automatic
Adjustment
(The servo is not locked to the
cylinder for more than 10 sec.)
VHS mode - Process
No.
-
80 An exceptional ejection depends on a
Error
VHS mode Refer to *Note 3 Process
No.
-
Note 1: Details of "VCR mode" of the Supplementary Data 1 (These values are hexadecimal indication)
0: STOP, 1: EJECT, 2: REW, 3: FF, 4:REV, 5: CUE, 6: SLOW, 7: POWEROFF, 8: PLAY, 9: STIL,
A: REC, B: REC PAUSE, C: ADUB, D: ADUB PAUSE, E: INSERT, F: INSERT PAUSE
Note 2: Explanation of "Tape position" of the Supplementary Data
The Tape position Data is the area data of S-reel that is used for judgment of reducing speed in the Main microprocessor IC6001, and as the
tape position is moved from the starting edge to the finishing edge, the value becomes smaller.
The Tape Data does not become "0" even if the tape reaches the finishing edge as the hub remains, and the tape position values are different
between the large hub and the small hub as the each diameters are different from each other.
70
