Note 3: Supplementary Data 2 (Reason of Ejection)
Supplementary Data 2 Reason
1 S-reel pulse is less than 3 when the loading has been completed.
(Miss catching the tape)
2 Pulse Timer over during the short rewind at the DOWN position.
(Error of S-photo sensor system, S-reel system, Capstan system)
3 Mechanism lock from the DOWN position to the LOAD position
loading.
4 Both ends have been detected at the LOAD position when the
started.
13. Assembling and Disassembling
13.1. Disassembly Flow Chart
The following chart is the procedure for disassembling the casing and inside parts for internal
inspection when carrying out the servicing.
To assemble the unit, reverse the steps shown in the chart below.
13.2. P.C.B. Positions
40
