Panasonic DMR-EH55EC

Item FL display Key operation
Mode name Description (Remote controller key)
Magenta Picture
Output
Magenta picture is output with
Component Output from AV
Decoder.
*Magenta picture
(Saturation rate: 100%)
*It is enable to switch Interlace/
Progressive by “I/P switch: [1]
[4]”
*Initial mode is “Interlace”. Press [1] [2] in service
mode.
Switch Interlace/
Progressive
Press [1] [4] in Magenta
Picture Output mode.
*I/P are switched
alternately.
RTSC Return in
XP
(A & V)
AV1 input signal is encoded (XP),
decoded (XP) and output
decoded signal to external
without DISC recording and DISC
playback.
Initial mode: EE2/ Interlace
/ XP/ Audio 48kHz
Press [1] [3] in service
mode.
Switch Interlace/
Progressive
Press [1] [4] in RTSC
Return XP mode.
*I/P are switched
alternately.
Audio 44.1 kHz/ 48 kHz
Switch
Press [2] [4] in RTSC
Return XP mode.
*48 kHz / 44.1 kHz are
switched alternately.
