Panasonic DMR-EH55EC

*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited for this item. After the discontinuation
of this assembly in production, it will no longer be available.
*“(IA)-(IH)”, marks in Remarks indicate languages of instruction manuals. [(IA): Polish, (IB):
English, (IC): German, (ID): Italian, (IE): Dutch, (IF): French, (IG): Spanish, (IH): Swedish/ Danish]
*Parts indicated with PAVC-CSG in the Remarks column are supplied by PAVC-CSG.
*All parts except parts indicated with (PAVC-CSG) in the Remarks column are supplied by
PAVCG.
Ref. No. Part No. Part Name & Description Pcs Remarks
RFKB79119JT MAIN P.C.B. (RTL)EPS,EPK
RFKB79119HT MAIN P.C.B. (RTL)ECS,ECK
RFKB79119GT MAIN P.C.B. (RTL)EGS,EGK
C1503 F2A1A6810022 10V 680P 1
C1504 F2A1E1010067 25V 100U 1
C1508 ECJ1VB1A105K 10V 1U 1
C1509 F1H1H1030006 50V 0.01U 1
C1510 ECJ1VB1A105K 10V 1U 1
C1511 ECJ1VB1A105K 10V 1U 1
C1512 ECJ1VB1A105K 10V 1U 1
C1515 F2A1E4700048 25V 47U 1
C1516 F2A1H1510006 50V 150P 1
C1518 F2A0J6810007 6.3V 680P 1
C1519 ECJ1VB1A105K 10V 1U 1
C1520 ECJ1VB1A105K 10V 1U 1
C1521 F2A1C121A453 16V 120P 1
C1522 ECJ1VB1A105K 10V 1U 1
C1523 F2A1A470A388 10V 47U 1
C1524 F2A1A101A389 10V 100U 1
C1525 F1H1C104A042 16V 0.1U 1
C1526 ECJ1VB1A105K 10V 1U 1
C1527 ECJ1VB1A105K 10V 1U 1
C1528 ECJ3YB1C105K 16V 1U 1
C1529 F2A1A470A388 10V 47U 1
C1535 ECJ1VB1A105K 10V 1U 1
C1536 F1J0J106A014 6.3V 10U 1
C1538 ECJ1VB1A105K 10V 1U 1
C1539 ECJ1VB1A105K 10V 1U 1
C1540 F1H1H1030006 50V 0.01U 1
C1541 F2A1E1010067 25V 100U 1
C1548 F2A1C121A453 16V 120P 1
C1549 F2A1C121A453 16V 120P 1
C3001 F1H1C104A042 16V 0.1U 1
C3002 F1H1H1030006 50V 0.01U 1
C3003 F1H1C104A042 16V 0.1U 1
C3004 F1H1C104A042 16V 0.1U 1
C3005 ECA0JM471B 6.3V 470U 1
C3006 ECA0JM471B 6.3V 470U 1
C3007 F2A1A4710038 10V 470U 1
C3008 F2A1A1010072 10V 100U 1
60
