5.2.4.5. Protocol Trace
Print a Protocol Trace Report for the previous communication.
Press the “V”, ”/\” arrow keys to select the "3: Print Report/List" on the display.
↓
Press the “SET” key to select the "1:Function Parameter List".
↓
Press the “V”, ”/\” arrow keys select the "6: Protocol Trace".
↓
Press the “SET” key.
↓
Press the “STOP” key twice to exit the service mode.
*************** PROTOCOL LOG. REPORT ****************** DATE MMM-dd-yyyy ***** TIME 16:56 *******
STATUS : OK
MODE : ECM-TX (STANDARD)
SPEED : 9600bps 0MS/L
REMOTE CAPA. : DIS 00 CE B9 C4 80 12
LOCAL CAPA. : TSI 2B 20 20 20 38 37 2B 2B 2B 2B
39 38 36 36 35 34 37 38 38 30
DCS 00 C6 F8 44
REMOTE : NSF CSI DIS CFR
COMMAND LOG.
LOCAL : TSI DCS PIX PPS-EOP
REMOTE : MCF
LOCAL : DCN
-PANASONIC -
****************************-PANASONIC -*************-12345678901234567890-***************
------------------------------------------------------------------
