207
UF-9000
APR 2006
Ver. 3.0
DP-180/190
nMVOL2 Monitor Volume Control Signal
nOPTION 2nd Feeder Option Detection Signal
nPON_OP 2nd Feeder No Paper Detection Signal
NPRDY Printer Ready
NPRINT Print Start
nPUCTL_OP 2nd Feeder Paper Pick up Control
NPURGE Paper End Detection Signal
nREGSEN REGISTRATION Sensor Signal
NRES Printer Reset
NSBSY Busy Status
nSCNDOR ADF Open / Close Detection Signal
nSCNRST Scanner Reset Signal
nSLPKY Energy Saver Key Signal
nSNRCLK LSU Motor Clock
nSNRCTL LSU Motor Control Signal
nSNRLD LSU Motor Lock Signal
nTESEN Low Toner Sensor Signal
NTOP Paper Top Detection Signal
nTOPSEN Paper Detect Sensor Signal
nTR Transfer (- Voltage PWM Pulse)
nTRCTL HVPS Transfer Control (+/- Change)
NVIDEO Video Data
nVIDEO Video Signal
nWAKEUP Wake Up Signal
OUT1 Motor Drive Signal
OUT2 Motor Drive Signal
OUT3 Motor Drive Signal
OUT4 Motor Drive Signal
pCMLD CML ON / OFF Select Signal
PNLRXD PNL Reception Data Signal
PNLTXD PNL Transmission Data Signal
PNON No Paper Sensor Signal
pPNLRST PNL Reset Signal
PS Parallel / Serial Data Input Select Signal
PSAVE Power Save Control Signal
PUSOL_CTL Pick Up Solenoid Control
PUSOL_CTL1 Pick Up Solenoid Control
REGSOL_CTL Registration Solenoid Control
RESETB LCD Driver Reset Signal
RS Register Selection Control Signal
RW_WRD Read/Write Execution Control Signal
RXD- LAN Receiving Data
RXD+ LAN Receiving Data
SCN[0] PNL Key Signal (Scan Line)
SCN[1] PNL Key Signal (Scan Line)
SCN[10] PNL Key Signal (Scan Line)
Glossary of Electrical Abbreviations
Signal Name Function
