Panasonic DVD-S42EE - Page 3

PAL: (576)p/(576)i]
(DVD-S42EE/GC/GCA/GCS/GCU)
[NTSC: (480)p/(480)i]
(DVD-S42PL/PLA)
Y output level: 1 Vp-p (75 )
P
B
output level: 0.7 Vp-p (75 )
P
R
output level: 0.7 Vp-p (75 )
Output terminal: Pin jack (Y: green, P
B
: blue,
P
R
: red)
Number of terminals: 1 system
RGB video output: (DVD-S42EE)
R output level: 0.7 Vp-p (75 )
G output level: 0.7 Vp-p (75 )
B output level: 0.7 Vp-p (75 )
Output terminal: AV
Video performance:
Horizontal resolution: More than 500 lines
Video S/N ratio: More than 65dB
Audio output:
Output level: 2 Vrms (1 kHz, 0 dB)
Output terminal: Pin jack/AV
(DVD-S42EE)
Pin jack
(DVD-S42GC/GCA/GCS/GCU/
PL/PLA)
Number of terminals:
2 channel: 1 system
Audio performance:
(1) Frequency response:
DVD (linear audio):
4 Hz-22 kHz (48 kHz sampling)
4 Hz-44 kHz (96 kHz sampling)
CD audio:
4 Hz-20 kHz
(2) S / N ratio:
CD audio:
115 dB
(3) Dynamic range:
DVD (linear audio):
102 dB
CD audio:
98 dB
(4) Total harmonic
distortion:
CD audio:
0.003 %
Digital audio output:
Coaxial digital output: Pin jack
Pickup
Wave length: 662 nm / 785 nm
Laser power: CLASS 2 / CLASS 3A
Note:
Specifications are subject to change without notice.
Mass and dimensions are approximate.
