6
DAILY USER´S MANUAL • EBL128 VERSION 2.2.X • DOCUMENT NUMBER: MEW01786 • REVISION: 1
2.2. PUSH BUTTONS
See reference picture on page 4.
17
Fault acknowledge
Used to acknowledge the faults shown in menu H6. Also used to
acknowledge SERVICE signal, see menu H8/S4.
18
Paper feed
Not used in EBL128.
19
Access
Used to log on and get access to the menu.
20
Return
Used to stop input of data, leave a menu ("one step up") and to log off.
21
C
Used to clear /delete just written data.
22
Key pad
Numeric key pad for the digits 0-9.
23
A
Used to accept / select a menu or input of data.
24
Left / right keys
Used to move the cursor in a menu.
25
Up / down keys
Used to scroll between the menus.
26
Alarms queued
Used when LEDs "Alarms queued" are lit. Scroll through the queued alarm
points or zone addresses.
27
Evacuate / Test LED
Used to activate all the sounders or test LED. (Option, only available for
some countries and conventions.)
28
Reset
Used to reset the fire alarms. Has to be pressed for > 0.5 sec.
29
Silence Alarm devices
Used to silence the alarm devices.
May be configured to disable alarm devices.
30
Silence buzzer
Used to silence the buzzer in the EBL 128 when it is sounding.
2.3. DISPLAY
See reference picture on page 4.
31
Display
This is the information the display will show in normal operation state.
 The user programmable information text is created via EBLWin.
 In normal operation and in quiescent state, the LCD-backlight will
be turned off.
 As soon as any other information is shown in the display, the
backlight is turned on.
