Panasonic EP30006

EP30006
ORDER NO.HPD0706U16C1
- 2 -
CONTENTS
Page
1 COMPONENTS IDENTIFICATION…………………………………………………………………………………………………………………………3
2 TURNING ON THE POWER………………………………………………………………………………………………………………………………7
3 REQUIRED TOOLS…………………………………………………………………………………………………………………………………………8
4 ADJUSTMENT OF PRESSURE SENSOR…………………………………………………………………………………………………………………9
5 OPERATIONS OF ELECTROMAGNETIC VALVES AND AIR BAGS………………………………………………………………………………10
6 DISPLAY METHOD OF MASSAGE BLOCK TOTAL USE TIME………………………………………………………………………………………11
7 DISPLAY METHOD OF EACH OPERATION USE TIME………………………………………………………………………………………………12
8 METHOD OF PACKAGING POSITION SET-UP…………………………………………………………………………………………………………12
9 METHOD OF MASSAGE MECHANISM BLOCK INSTALLATION MODE SET-UP (MANUAL SET-UP)…………………………………………13
10 DISASSEMBLY……………………………………………………………………………………………………………………………………………14
11 ACTUAL WIRING DIAGRAM……………………………………………………………………………………………………………………………44
12 PHENOMENA CAUSED BY THE SENSOR MALFUNCTION OR LOCK PROTECTION OPERATION…………………………………………47
13 CHECKING…………………………………………………………………………………………………………………………………………………49
14 GREASE……………………………………………………………………………………………………………………………………………………57
15 EXPLODED VIEW…………………………………………………………………………………………………………………………………………60
16 REPLACEMENT PARTS LIST……………………………………………………………………………………………………………………………66
