16. REPLACEMENT PARTS LIST
R
e
f
.
N
o.
P
ar
t
N
o.
P
ar
t
N
ame
&
D
escr
i
p
ti
on
R
emar
k
s
P
er
U
n
it
1 WEP3530L0087 REAR FRAME 1
2 WEP3530L0007 SIDE HINGE FITTING RIGHT 1
3 WEP3530L0017 SIDE HINGE FITTING LEFT 1
4 WEP3530L6717 SCREW 8
5 WEP3200L0887 RESING BUSHING 12
6 WEP3530L0267 REAER COVER FXING PLATE 1
7 WEP2000L9567 SCREW
*
55
8 WEP2005L0687 CORD WIRE
*
1
9 WEP3530L0767 RAIL PIECE RIGHT 1
10 WEP3530L0777 RAIL PIECE LEFT 1
11 WEP573L6627 SCREW
*
16
12 WEP2110L0907 HINGE PIN A2
*
2
13 WEP3530L1538 RECLINING LIFT UNIT 1
14 WEP3530L1528 OTTOMAN LIFT UNIT 1
15 WEP3010L0417 OTTOMAN LIFT PIN LONG 4
16 WEP3530K1568 LEG SLIDE LEVER 1
16 WEP3530C1568 LEG SLIDE LEVER 1
17 WEP3530K0097 UNDER PIPE 1
18 WEP3510L0497 S SCREW
*
1
19 WEP3530L0277 STAND INSTALL FITTING RIGHT 1
20 WEP3530L0287 STAND INSTALL FITTING LEFT 1
21 WEP3530L9317 SCREW 2
22 WEP2000L9577 SCREW
*
11
23 WEP3530K3907 CASTER 2
24 WEP3530L0917 HINGE PIN A 2
25 WEP596N0357 SNAP PIN
*
8
26 WEP578K3377 BOTTOM PLATE 4
27 WEP3510S9027 SCREW 35
28 WEP2200L0147 2 ROW JOINT 2
29 WEP2110L0147 3 ROW JOINT 1
30 WEP3530K3187 SCREW COVER 6
31 WEP3530K3138 LEG COVER RIGHT 1
32 WEP3530K3158 LEG COVER LEFT 1
33 WEP780L0447 MASSAGE BLOCK CLIP 4
34 WEP3510L0317 HOSE CLIP 5437 1
35 WEP3200L0277 HOSE CLIP 1J98 1
36 WEP005W8517 INSULATED TIE MEDIUM 3
37 WEP005W8527 INSULATED TIE LARGE 1
38 WEP3530K2008 POWER SWITCH BLOCK 1
39 WEP3530K3098 POWER SOURCE COVER
*
1
40 WEP3510K3287 LOCK BUTTON 1
41 WEP760K3257 SWITCH 1
42 WEP3510L2327 MICRO SWITCH SHEET 1
43 WEP3010L2027 MICRO SWITCH
*
1
44 WEP3510S9087 SCREW 1
45 WEP2400L9067 SCREW
*
2
46 WEP3530K2058 POWER CORD 1
47 WEP3530H7868 LOCK KEY
*
1
48 WEP3010S9087 SCREW 2
49 WEP3530K3758 OTTOMAN COVER K 1
49 WEP3530T3758 OTTOMAN COVER T 1
50 WEP3530L0627 SOLE SHIATSU SHEET RIGHT 1
