• Mount the battery
Step 1 Mount the base
1
.
5
7 i
n
4
0 m
m
1.57 in
40 mm
Mark
1
2
3
Hand remove
Marker
Measuring tape
13
12
Step 2 Mount the battery module
1
2
3
Hand remove
M5
8.8 lbf.in /
1.0 N·m
Mechanical InstallationMechanical Installation
Bottom view
Top view
M8*85 × 4
