Mechanical InstallationMechanical Installation
Marker
Cross screwdriver
Spirit level
4
5
M5
8.8 lbf.in /
1.0 N·m
15
CAUTION!
Please re-mount the dust cover to the battery module before drilling
holes to avoid dust falling into the interface and do remember to
remove the dust cover again after the installation wall bracket
completed.
32 in
/8
1
2
.
8 m
m
6
7
14
Attach screw but
not tighten
Mark
Ø 0.39 in./10 mm for
Wall Bracket
