Verify Panasonic Clutch Tools On Applications
1. Application Specifications – Record to Worksheet
•Specs – Obtain the target torque, tolerance, extensions and socket/bit for the application.
2. Set Up Tool – Update Worksheet
• Adjust The Torque – Use the clutch adjustment tool to increase (cw) or decrease (ccw) the output
torque.
• Program The Tool – Program the tools speed to meet the application and enable additional quick
features if necessary.
3. Verify The Tool In The Calibration Lab – Update Worksheet
• Set Up Transducer – Set up the Analyzer/Software per the settings recorded in the worksheet.
• Adjust Simulator – Adjust the Joint Simulator to the joint type recorded in the worksheet.
• Transducer – Warm up the Joint Simulator and Tool before testing. Run 10 cycles on the joint
simulator to get the components warmed up and grease moving.
• Run The Tool – Run the tool on the Transducer with the Joint Simulator.
4. & 5. Run The Tool On The Application – Update Worksheet
• Run The Tool - Run the tool on the application and be sure to hold the trigger until the tool shuts off.
•Audit The Fastener - Conduct a residual audit of the fastener to verify accuracy.
• Adjust Torque - If the torque is out of specification, adjust the tools clutch to increase or decrease
the torque until the residual audit is within specification.
6. Record / Tool History
• Worksheet – Update the worksheet with the above information if any changes were made to the
tool, settings or attachments.
Panasonic Assembly
Tools Set Up Worksheet
Panasonic Life Solutions Company of America Assembly Tools Division
2 Riverfront Plaza 5
th
Floor Newark, NJ 07102
www.panasonic.com/assemblytools
