Panasonic EYFLA4 - Setup Worksheet

Application
Tool Info
Accessories
Residual Audit
Setup Worksheet
Production Floor Information
Calibration Unit Settings
Single Tool Worksheet
Calibration Lab Information
Brand of Sockets / Extensions / Etc.
Apex
Sockets / Extensions / Etc.
Audit
13mm
Certification Results (Nm (+/- % or +/- Nm))
20 +/-20%
Flush Point (L1/L2)
L2
Tool Program Setting (1~30)
18
Accessories
Target Torque
20
Torque High Limit
23
Torque Low Limit
17
Filter Frequency Setting (Hz)
500
Pulse Tool Compensation
1-800
Torque Units (Nm, Ft. Lbs., In. Lbs., Etc.)
Nm
Joint Simulator Model #
EYFJS22NM
Joint Type / Setting
Medium Hard
Mode
Pulse
Serial #
123456
Transducer Model #
EYFST22NM
Transducer Serial #
123456
Residual Audit Torque (Nm)
21
Calibration Date
2014-01-01
Model #
EYFST22NM
Sockets / Extensions / Etc.
13mm w/ 10" Ext
Audit Wrench Make
Brand
Audit Wrench Model/Serial #
ABC/123
Audit Wrench Mode
Peak
Audit Wrench Settings
Torque/Angle/Threshold
Tool Model Number
EYFLA5A
Tool Serial Number
YLA5AR1212074
Flush Point (L1/L2)
L2
Tool Program Setting (1~30)
18
Brand of Sockets / Extensions / Etc.
Apex
Target Torque
20
Torque Tolerance (+/- %)
15%
Torque Tolerance (+/-)
3
Date of Install
2014-01-01
Application
Hood Install
Location
H26
Torque Units (Nm, Ft. Lbs., In. Lbs., Etc.)
Nm
