VIII . SPECIFICATIONS
MAIN UNIT
Model EYFLA4 EYFLA5 EYFLA6
A,AR A AR P,Q
PR,QR J,P JR,PR
Motor 10.8 V DC
Chuck size Single-ended 9 – 9.5 mm
(23/64” – 3/8”)
9 – 9.5 mm
(23/64” – 3/8”)
□
9.5 mm (3/8”)
□
12.7 mm (1/2”)
Double-ended 12 mm (15/32”) 12 mm (15/32”)
No load speed Stage 1
2
3
4 – 8
9 – 30·F
0 – 950
0 – 1300
0 – 1450
0 – 1550
0 – 2300
1
2
3
4 – 30·F
0 – 1300
0 – 1450
0 – 1550
0 – 2300
0 – 2300
Impact per
minute
Stage 1
2
3
4 – 8
9 – 30·F
0 – 1900
0 – 2500
0 – 2800
0 – 3000
0 – 4000
1
2
3
4 – 30·F
0 – 2500
0 – 2800
0 – 3000
0 – 3600
0 – 3000
Maximum torque 40 N·m
(408 kgf-cm, 354 in-lbs)
90 N·m
(918 kgf-cm, 796 in-lbs)
120 N·m
(1224 kgf-cm, 1062 in-lbs)
Torque control function
operating range
Approx. 3 – 22 N·m
(31 – 224 kgf-cm,
27 – 195 in-lbs)
Approx. 6 – 30 N·m
(61 – 306 kgf-cm,
53 – 266 in-lbs)
Approx. 16 – 53 N·m
(163 – 540 kgf-cm,
142 – 469 in-lbs)
Overall length
158 mm (6-7/32”) 164 mm (6-7/16”) 172 mm (6-25/32”)
Weight (with battery pack: EYFB30) 1.3 kg (2.9 lbs) 1.3 kg
(2.9 lbs)
1.35 kg
(3.0 lbs)
1.3 kg
(2.9 lbs)
1.35 kg
(3.0 lbs)
1.4 kg (3.1 lbs)
Weight (with battery pack: EYFB32) 1.15 kg (2.5 lbs) 1.15 kg
(2.5 lbs)
1.2 kg
(2.6 lbs)
1.15 kg
(2.5 lbs)
1.2 kg
(2.6 lbs)
1.25 kg (2.8 lbs)
Model EYFLA7 EYFLA8 EYFLA9 EYFMA1 EYFMA2
A,AR
A,AR C,CR P,PR C,CR P,PR J,JR P,PR C,CR P,PR
Motor 10.8 V DC 14.4 V DC
Chuck size Single-ended 9 – 9.5 mm
(23/64” – 3/8”)
□
9.5 mm
(3/8”)
□
12.7 mm
(1/2”)
□
12.7 mm
(1/2”)
□
12.7 mm
(1/2”)
Double-ended
12 mm (15/32”)
No load speed Stage 1
2
3
4 – 8
9 – 30·F
0 – 950
0 – 1300
0 – 1450
0 – 1550
0 – 2300
1
2
3
4 – 30·F
0 – 1300
0 – 1450
0 – 1550
0 – 2300
0 – 2300 0 – 2300 0 – 2300
Impact per
minute
Stage
1
2
3
4 – 8
9 – 30·F
0 – 1900
0 – 2500
0 – 2800
0 – 3000
0 – 4000
1
2
3
4 – 30·F
0 – 2500
0 – 2800
0 – 3000
0 – 3600
0 – 2800 0 – 3200 0 – 2900
Maximum torque
35 N·m
(360 kgf-cm,
310 in-lbs)
80 N·m
(820 kgf-cm,
709 in-lbs)
120 N·m
(1224 kgf-cm,
1062 in-lbs)
185 N·m
(1887 kgf-cm,
1637 in-lbs)
185 N·m
(1887 kgf-cm,
1637 in-lbs)
Torque control function
operating range
Approx. 3 – 22 N·m
(31 – 224 kgf-cm,
27 – 195 in-lbs)
Approx. 6 – 30 N·m
(61 – 306 kgf-cm,
53 – 266 in-lbs)
Approx. 20 – 60 N·m
(204 – 612 kgf-cm,
177 – 529 in-lbs)
Approx. 25 – 100 N·m
(255 – 1020 kgf-cm,
310 – 885 in-lbs)
Approx. 25 – 120 N·m
(255 – 1223 kgf-cm,
310 – 1058 in-lbs)
Overall length 156 mm (6-5/32”) 162 mm (6-3/8”) 172 mm (6-25/32”) 172 mm (6-25/32”)
Weight (with battery pack: EYFB30) 1.45 kg (3.2 lbs) 1.6 kg (3.5 lbs) 1.45 kg (3.2 lbs) ———— ————
Weight (with battery pack: EYFB32) 1.3 kg (2.9 lbs) 1.4 kg (3.1 lbs) 1.3 kg (2.9 lbs) ———— ————
Weight (with battery pack: EYFB41) ———— 1.3 kg (2.9 lbs) 1.4 kg (3.1 lbs)
Weight (with battery pack: EYFB42) ———— 1.5 kg (3.3 lbs) 1.6 kg (3.5 lbs)
