Remote control (not included with shipment)
Model EYFA31
Battery voltage 3 V DC
Dimensions 54 mm (2-1/8”) × 86 mm (3-3/8”) × 10 mm (13/32”)
Weight (with battery)
Approximately 30 g
(0.06 lbs)
Assembly Qualifier (not included with shipment)
Model EYFR02
Rating See the rating plate on the bottom of the Assembly Qualier.
Dimensions 120 mm (4-3/4”) × 260 mm (10-1/4”) × 70 mm (2-3/4”)
Weight 1.1 kg (2.4 lbs)
Radio Information
Model EYFLA
Indoor/Urban Range 100 ft./ 30 m
Outdoor RF line-of-sight range 300 ft./100 m
Transmit Power 1 mW (0 dBm)
Assembly Qualier Sensitivity -92 dBm (1% packet error)
FCC Part 15.249 O4O-EYFLA
Industry Canada 8507A-EYFLA
Channel Frequencies:
Channel 1 2.410 GHz Channel 7 2.440 GHz
Channel 2 2.415 GHz Channel 8 2.445 GHz
Channel 3 2.420 GHz Channel 9 2.450 GHz
Channel 4 2.425 GHz Channel 10 2.455 GHz
Channel 5 2.430 GHz Channel 11 2.460 GHz
Channel 6 2.435 GHz Channel 12 2.465 GHz
CAUTION:
• The above wireless device may experience electric wave interference, and thus
should not be used for human safety-related services.
IX
. HARMONIZED STANDARDS
MAIN UNIT
Conforms to UL Std.60745-1 & 60745-2-2
Certified to CSA Std.C22.2 No. 60745-1 & 60745-2-2
BATTERY CHARGER
Conforms to UL Std.1310
Certified to CSA Std.C22.2 No. 223-M91
5007005
