. OPERATION
Registering the tool with the assembly qualifier
● Preparing the assembly qualifier
1. Connect the power cord to the assembly qualifier.
2. Plug the power cord into a wall outlet.
3. Turn on the assembly qualifier.
All indicators will turn on and off, leaving only the power indicator on.
4. Insert a mode switching key into the key lock and turn to the left.
The power indicator will flash, and the assembly qualifier will enter tool
registration standby mode.
● Preparing the tool to be registered
1. Operate the tool so that all the panel lights are off (if any panel lights are on).
2. Pull the tool’s trigger.
Once the tool has been registered, the assembly qualifier’s fastening PASS
signal will turn on.
3. Turn the assembly qualifier’s mode switching key to the right.
The power indicator will turn on and the assembly qualifier will enter receive
mode, completing the registration process.
CAUTION
The registration procedure should be performed away from other transmitter-
equipped tools. When registering multiple tools, do so one pair at a time. Failure to
do so may cause an unintended tool to be registered with the assembly qualifier.
Indicators
Indicator State
Fastening
PASS indicator
Green Fastening PASS signal received.
Off No fastening PASS signal is being received.
Fastening
FAIL indicator
Red Fastening FAIL signal received.
Off No fastening FAIL signal is being received.
Power indicator
Blue Power on (receive mode)
Off Power off
Flashing blue Tool registration standby mode
Signal strength
indicator
Yellow Strong signal
Orange Medium-strength signal
Red Weak signal
Off No fastening signal is being received.
