Panasonic EYFR02 - FUNCTIONAL DESCRIPTION; I;O Connector; Beeper; Volume Switch

- 2 -
Index
English: Page 3
FUNCTIONAL DESCRIPTION
(A)
I/O connector
(B)
Beeper
(C)
Volume switch
(D)
Fastening PASS indicator
(E)
Antenna
(F) Fastening FAIL indicator
(G)
Mounting holes
(H)
Signal strength indicator
(I)
Power indicator
(J) Key lock
(K) D-sub 9-pin female inch thread
(L)
Power switch
(M)
Power plug inlet
(N)
Mode switching keys (2)
(O)
Power cord
