8.3. Disassembly Procedure
No. Item Fig Removal
1 Side Case (L) Unit Fig.D1 2 Screws (A)
4 Screws (B)
2 Locking tabs
Sensor Cover Unit
Fig.D2 3 Screws (C)
4 Locking tabs
Side Case (L) Unit
2 HDD Fig.D3 PP6001 (Connector)
2 HDD Cushions
HDD
3 HDD Gnd Case Unit Fig.D4 4 Screws (D)
1 Screw (E)
1 Rib
HDD Gnd Case Unit
4 Top Case Unit Fig.D5 1 Screw (F)
1 Screw (G)
1 Screw (H)
1 Screw (I)
Fig.D6 2 Locking tabs
SR Cover
1 Screw (J)
PS6002 (Connector)
2 Ribs
1 Locking tab
FP6301 (Flex)
Top Case Unit
5 Front Unit Fig.D7 P7001 (Connector)
P7002 (Connector)
1 Screw (K)
1 Rib
1 Locking tab
FP6403 (Flex)
Front Unit
6 Side Case (R) Unit Fig.D8 4 Screws (L)
1 Screw (M)
PS6003 (Connector)
FP6501 (Flex)
Side Case (R) Unit
7 Batt Case Unit Fig.D9 1 Screw (N)
1 Screw (O)
2 Ribs
PP6005 (Connector)
Batt Case Unit
8 Lens Unit Fig.D10 2 Screws (P)
1 Rib
2 Projection parts
Fig.D11 PP6004 (Connector)
PP6007 (Connector)
FP6002 (Flex)
1 Screw (Q)
Lens Frame Unit
Lens Unit
9 Main P.C.B. Unit Fig.D12 3 Screws (R)
2 Ribs
Main Heat Radiation Plate
Fig.D13 PP6006 (Connector)
1 Projection part
Main P.C.B. Unit
10 Flash P.C.B. Unit Fig.D14 2 Screws (S)
1 Projection part
Flash P.C.B. Unit
11 Side (R) OP P.C.B.
Unit
Speaker
Fig.D15 2 Screws (T)
SP Angle
PS6501 (Connector)
P6501 (Connector)
Speaker
Side (R) OP P.C.B. Unit
Fig.D16 NOTE: (When Installing)
12 Fan Motor Fig.D17 3 Convexes
Fan Damper
Fan Motor
13 LCD Case Unit Fig.D18 2 Screws (U)
Holder
Switch Unit
3 Locking tabs
Earth Plate
Sheet
Light Guide Plate
3 Ribs
LCD Case Unit
14 Monitor P.C.B. Unit Fig.D19 FP904 (Flex)
FP905 (Flex)
2 Ribs
2 Convexes
LCD Frame
Fig.D20 FP903 (Flex)
4 Locking tabs
Monitor P.C.B. Unit
Fig.D21 1 Locking tab
Reflection Sheet
Light Guide Plate
Diffusion Sheet
Prism Sheet B
Prism Sheet A
Lighting Plate Holder
Monitor P.C.B. Unit
15 Front P.C.B. Unit Fig.D22 1 Screw (V)
1 Screw (W)
FP6400 (Flex)
FP6402 (Flex)
Front P.C.B. Unit
16 Barrier Motor Unit Fig.D23 1 Screw (X)
Barrier Motor Unit
Fig.D24 NOTE: (When Installing)
17 Front Case Fig.D25 Lens Ornament Sheet
Fig.D26 4 Screws (Y)
Front Case
18 MF SENS P.C.B. Unit
Front Case Unit
MF Front Frame
MF Sheet
Fig.D27 1 Screw (Z)
MF P.C.B. Holder
MF SENS P.C.B. Unit
Front Case Unit
MF Front Frame
MF Sheet
Fig.D28 NOTE: (When Replacing)
19 EVF Unit Fig.D29 2 Screws (a)
1 Screw (b)
EVF Unit
20 Shoe Angle
Top Frame
Shoe Cover
Fig.D30 3 Screws (c)
Shoe Angle
Fig.D31 4 Screws (d)
1 Locking tab
Top Frame
Shoe Cover
No. Item Fig Removal
