Panasonic HDC-HS700P - S2. Voltage Chart; S2.1. Strobe P.C.B; S2.3. MIC Amp P.C.b; S2.4. Batt_Catcher P.C.B

S-2
Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
REF No. PIN No. POWER ON
IC7001 1 0
IC7001 2 0
IC7001 3 0
IC7001 4 0
IC7001 5 3.3
IC7001 6 0
IC7001 7 0
IC7001 8 0
IC7001 9 2.9
IC7001 10 8.3
Q3901 E 3.3
Q3901 C 3.3
Q3901 B 3.3
S2. Voltage Chart
S2.1. Strobe P.C.B. S2.2. Front P.C.B.
REF No. PIN No. POWER ON
Q4901 E 0.5
Q4901 C 3.9
Q4901 B 1
Q4902 E 4.5
Q4902 C 2.9
Q4902 B 3.9
Q4903 E 0.5
Q4903 C 3.9
Q4903 B 1
Q4904 E 4.5
Q4904 C 2.9
Q4904 B 3.9
Q4907 E 4.5
Q4907 C 5.1
Q4907 B 5.1
Q4908 E 2.8
Q4908 C 4.5
Q4908 B 3.4
Q6401 E 5.1
Q6401 C -0.4
Q6401 B 5.1
QR6401 E 0
QR6401 C 4.8
QR6401 B 0
S2.3. MIC AMP P.C.B.
REF No. PIN No. POWER ON
IC4801 1 2.5
IC4801 2 2.5
IC4801 3 2.5
IC4801 4 0
IC4801 5 2.5
IC4801 6 2.5
IC4801 7 2.5
IC4801 8 4.8
IC4802 1 2.5
IC4802 2 2.5
IC4802 3 2.5
IC4802 4 0
IC4802 5 2.5
IC4802 6 2.5
IC4802 7 2.5
IC4802 8 4.8
IC4803 1 2.5
IC4803 2 2.5
IC4803 3 2.5
IC4803 4 0
IC4803 5 2.5
IC4803 6 2.5
IC4803 7 2.5
IC4803 8 4.8
Q4801 E 4.1
Q4801 C 4.8
Q4801 B 4.8
S2.4. BATT_Catcher P.C.B.
REF No. PIN No. POWER ON
IC6302 1 3.2
IC6302 2 0
IC6302 3 0
IC6302 4 2.9
IC6302 5 3.2
IC851 1 0
IC851 2 0
IC851 3 0
IC851 4 0
IC851 5 0
IC851 6 0
IC851 7 0
IC851 8 0
IC851 9 0
IC851 10 0
IC851 11 0
IC851 12 0.7
IC851 13 0.7
IC851 14 0
IC851 15 0
IC851 16 0
IC851 17 0
IC851 18 0
IC851 19 0
IC851 20 0
IC851 21 0
IC851 22 0
IC851 23 0
IC851 24 0.2
IC851 25 0
IC851 26 0
IC851 27 0
IC851 28 0
IC851 29 0
IC851 30 0
IC851 31 0
IC851 32 0
IC851 33 0.1
IC851 34 0
IC851 35 0
IC851 36 0
IC851 37 0
IC851 38 0
IC851 39 0
IC851 40 0
IC851 41 0
IC851 42 0
IC851 43 0
IC851 44 0
IC851 45 0
IC851 46 0
IC851 47 0
IC851 48 0
IC851 49 0
IC851 50 0
IC851 51 0
IC851 52 0
IC851 53 0
IC851 54 0
IC851 55 0
IC851 56 0
IC851 57 0
IC851 58 0
IC851 59 0
IC851 60 0
IC851 61 0
REF No. PIN No. POWER ON
IC851 62 0
IC851 63 0
IC851 64 0
