LED+USB Board
(1) Connector for LCD to MB board ： 10 pin connector (
1.25mm Pitch PicoBlade series / Molex )
PIN# Signal PIN# Signal
1 GND 6 GND
2 Power LED Green 7 USB_OC#
3 Power LED Red 8 USB D+
4 LAN LED 9 USB D-
5 HDD LED 10 +5 V (USB)
(2) USB for Wi-Fi module ： USB connector Type A
PIN# Signal PIN# Signal
1 +5 V (USB) 3 USB D+
2 USB D- 4 GND
(3) Speaker ： 2 pin connector (
1.25mm Pitch PicoBlade series / Molex)
PIN# Signal PIN# Signal
1 SP+ 2 SP-
