Pin Descriptiojn I/O Hi Hi-z Low Remarks
63 Serial Data(I2C) D.I/O Data - Data -
64 Serial Clk(I2C) D.I/O Active - Active -
65 Address Bus D.O - - - for Flash Memory
66 Address Bus D.O - - - for Flash Memory
67 MODE D.I - - (Fixed) -
68 WR D.O - - Write IC4 for Flash Memory
69 R2/P1.7 D.O - - (Fixed) -
70 Address Bus D.O - - - for Flash Memory
71 Bell/Paging LED D.O LED ON - LED OFF -
72 VBACK A.I - - - -
73 VSS - - - - -
74 Address Bus D.O - - - for Flash Memory
75 Address Bus D.O - - - for Flash Memory
76 DSPIN/P1.O D.I - - (Fixed)
77 Address Bus D.O - - - for Flash Memory
78 DSPOUT/P1.1 D.I (Fixed) - -
79 Address Bus D.O - - - for Flash Memory
80 DSPCLK/P1.2 D.I - - (Fixed)
81 Address Bus D.O - - - for Flash Memory
82 DSPFRM/P1.3 D.O - - (Fixed)
83 OE D.O - - Read IC4 for Flash Memory
84 VSS - - - - -
85 VDD - - - - -
86 Address Bus D.O - - - for Flash Memory
87 Key IN D.I No Key - Key -
88 (NO USE) D.I - - (I PD) -
89 CE D.O - - IC4 Active for Flash Memory
90 (NO USE) D.O - - - -
91 (NO USE) D.O - - - -
92 Data Bus D.I/O - - - for Flash Memory
93 (NO USE) D.I - - (I PD) -
94 (NO USE) D.I - - (I PD) -
95 HOOK CTRL D.O Make Break -
96 Data Bus D.I/O - - - for Flash Memory
97 (NO USE) D.O - - - -
98 Data Bus D.I/O - - - for Flash Memory
99 ANT1 D.O ANT1 ON - ANT1 OFF -
100 ANT2 D.O ANT2 ON - ANT2 OFF -
Note:
I_PU; Internal Pull-Up, I_PD; Internal Pull-Down
66
KX-TCD450RUM / KX-A145RUM / KX-TCD450RUT / KX-A145RUT
