Useful Information
Wall MountiMng
This unit can be mounted on a wall.
- Insert screws into the wall. The centre of the screw holes should be 8 cm horizontally
apart.
- Make sure the screws are securely fastened to the wall.
- Connect the AC adaptor and the telephone line cord.
- Arrange the wires as shown, then mount the unit.
• Make sure the screws are securely fastened to the wall.
8 cm
Screws
Fasten the AC adaptor cord to
prevent it from being disconnected.
Hooks
8 cm
Wall Template
