4.6 CO Line Programming
Pulse Speed Selection
4-84 System Programming
403
Description A CO line set for pulse or call blocking mode in program [402]
“Dial Mode Selection” can have two pulse rates, 10 pps (low) and
20 pps (high). This program sets the pulse speed for each CO line
set to pulse or call blocking mode.
Selection • CO line number:
KX-TD816 – 01 through 08, ( =all CO lines)
KX-TD1232 – 01 through 24, ( =all CO lines)
• 10 pps / 20 pps
Default All CO lines – 10 pps
Programming 1. Enter 403.
Display: Pulse Speed
2. Press NEXT.
Display: CO Line NO?–>
3. Enter a CO line number.
To enter CO line number 01, you can also press NEXT.
Display example: CO01:10pps
4. Keep pressing SELECT until the desired selection is
displayed.
5. Press STORE.
6. To program another CO line, press NEXT or PREV, or
SELECT and the desired CO line number.
7. Repeat steps 4 through 6.
8. Press END.
Conditions • In the case of KX-TD1232, CO01 through CO12 are for the Master
System and CO13 through CO24 are for the Slave, if available.
• To assign all CO lines to one selection, press the key at step 3. In
this case, the display shows the contents programmed for CO01.
• The pulse speed required is determined by the CO or PBX line.
• Program [990] “System Additional Information, Field (17) and Field
(21)” are used to select a pulse break ratio and inter-digit pause, if
needed.
Feature References Section 3, Features,
Dial Type Selection
