LED Indications (KX-TDA0155/KX-TDA0156/KX-TDA0158)
Indication Colour Description
STATUS Green/Red CS status indication
• OFF: Power Off
• Green ON: Stand-by (no active calls)
• Slow Green Flashing (60 times per minute): Talk (active calls)
• Moderate Green Flashing (120 times per minute): Busy
• Red ON: Fault (includes Initialisation)
• Red Flashing (60 times per minute): Out of Service/Starting up
CS status indication during the site survey
• Red ON: The CS is connected to an AC adaptor/battery box.
• Red Flashing (60 times per minute): The CS is connected to the
PBX.
Compatible PBX
Cell Station
PBX
Model No. MPR Software Version
KX-TDA0155/
KX-TDA0141
KX-TDA15 PSMPR Software File Version 1.1000 or later
KX-TDA30 PSMPR Software File Version 1.0000 or later
KX-TDA100
PMPR Software File Version 1.1000 or later
KX-TDA200
KX-TDA600 PLMPR Software File Version 2.2000 or later
KX-TDE100
PMMPR Software File Version 1.0000 or later
KX-TDE200
KX-TDE600 PGMPR Software File Version 2.0000 or later
KX-NCP500
PBMPR Software File Version 1.0000 or later
KX-NCP1000
KX-TDA0156/
KX-TDA0142
KX-TDA100
PMPR Software File Version 1.0000 or later
KX-TDA200
KX-TDA600 PLMPR Software File Version 2.2000 or later
KX-TDE100
PMMPR Software File Version 1.0000 or later
KX-TDE200
KX-TDE600 PGMPR Software File Version 2.0000 or later
Quick Installation Guide 7
1 Overview
