PBX Connected via
Maximum Number
KX-TDA0158
KX-TDA0155/
KX-TDA0141
KX-TDA0156/
KX-TDA0142
KX-TDA15
• Super Hybrid
Ports
• DLC card
2 4 -
KX-TDA30
(with Additional AC
Adaptor)
• Super Hybrid
Ports
• DLC card
4 8 -
KX-TDA100/
KX-TDA200
• DHLC card
• DLC card
16 32 -
• CSIF card
- - 32
KX-TDA600
• DHLC card
• DLC card
64 128 -
• CSIF card
- - 128
KX-TDE100/
KX-TDE200
• DHLC card
• DLC card
16 32 -
• CSIF card
- - 32
KX-TDE600
• DHLC card
• DLC card
64 128 -
• CSIF card
- - 128
KX-NCP500
• DHLC card
• DLC card
2 4 -
KX-NCP1000
• DHLC card
• DLC card
4 8 -
Required Distances between Equipment
CAUTION
Maintain the distances listed below between equipment in order to prevent noise, interference or the
disconnection of a conversation. (The distance may vary depending on the environment.)
Equipment Distance
CS and office equipment such as a computer, telex, fax
machine, etc.
More than 2 m
CS and PS More than 1 m
Each CS More than 3 m
Each PS More than 0.5 m
PBX and CS More than 2 m
Quick Installation Guide 9
1 Overview
