Panasonic KX-TDA100

4. Slide the wall mounting plate in the direction of the arrow until it clicks.
KX-TDA0155
KX-TDA0158
5. Hook the CS on the screw heads.
KX-TDA0155
Washer
Drive the screw
to this point.
KX-TDA0158
Drive the screw
to this point.
Washer
6. Place the antennas so that they are pointing in directions that are 90 degrees apart (for antenna diversity),
as follows:
45º
45º
90º
236 Installation Manual
2.10.8 Wall Mounting
