Panasonic KX-TDA100

Model No. Model Name Description
KX-TDA0175 16-Port Single Line Telephone
Extension
with
Message
Lamp Card
(MSLC16)
16-port extension card for SLTs with Message
Waiting Lamp control and 4 power failure transfer
(PFT) ports. Maximum power output of 160 V/90
V for Message Waiting Lamp control.
KX-TDA0177 16-Port Single Line Telephone
Extension Card with Caller ID
(CSLC16)
16-port extension card for SLTs with Caller ID
(FSK) and 4 power failure transfer (PFT) ports.
KX-TDA0180 8-Port Analogue Trunk Card
(LCOT8)
8-port analogue trunk card with 2 power failure
transfer (PFT) ports.
KX-TDA0181 16-Port Analogue Trunk Card
(LCOT16)
16-port analogue trunk card with 4 power failure
transfer (PFT) ports.
KX-TDA0182 8-Port DID Card (DID8) 8-port DID trunk card.
KX-TDA0183 4-Port Analogue Trunk Card
(LCOT4)
4-port analogue trunk card with 2 power failure
transfer (PFT) ports.
KX-TDA0184 8-Port E & M Trunk Card (E&M8) 8-port E & M (TIE) trunk card. Type 5 support.
KX-TDA0187 T-1 Trunk Card (T1) 1-port T1 trunk card. EIA/TIA standard compliant.
KX-TDA0188 E-1 Trunk Card (E1) 1-port E1 trunk card. ITU-T standard compliant.
KX-TDA0189 8-Port Caller ID/Pay Tone Card
(CID/PAY8)
8-port Caller ID signal type FSK/FSK (with Call
Waiting Caller ID [Visual Caller ID])/DTMF, and
8-port Pay Tone Service (12 kHz/16 kHz). To be
mounted on the ELCOT16 card.
KX-TDA0190 Optional 3-Slot Base Card (OPB3) Optional 3-slot base card for mounting a maximum
of 3 optional service cards from the following:
MSG4, ESVM4, ESVM2, DPH4, DPH2 or EIO4
card.
KX-TDA0191 4-Channel Message Card (MSG4) 4-channel message card. To be mounted on the
OPB3 card.
KX-TDA0192 2-Channel Simplified Voice
Message Card (ESVM2)
2-channel simplified voice message card for
Built-in Simplified Voice Message feature. Also
supports MSG card features. To be mounted on
the OPB3 card.
KX-TDA0193 8-Port Caller ID Card (CID8) 8-port Caller ID signal type FSK/FSK (with Call
Waiting Caller ID [Visual Caller ID])/DTMF. To be
mounted on the ELCOT16 card.
KX-TDA0194 4-Channel Simplified Voice
Message Card (ESVM4)
4-channel simplified voice message card for
Built-in Simplified Voice Message feature. Also
supports MSG card features. To be mounted on
the OPB3 card.
KX-TDA0196 Remote Card (RMT) Analogue modem card for remote communication
with
the PBX.
ITU-T V.90 support. To be mounted
on the MPR card.
26 Installation Manual
1.3.1 Optional Equipment
