Connector Type Pin Number Used for
10-pin
Terminal
Block
8-pin
Terminal
Block
8
1
10
1
• DPH4 (KX-TDA0161)
• DPH2 (KX-TDA0162)
• EIO4 (KX-TDA0164)
RS-232C
(Shielded cable)
9 5
6 1
• IP-GW4 (KX-TDA0480)
• Basic Shelf
USB
2
1
3
4
• MPR
Mini Plug
2
4
• MPR
