Ref. No. Part No. Part Name & Description Remarks
PCB3 PQLP10243Z RF BLOCK
23.2. Handset
23.2.1. CABINET AND ELECTRICAL PARTS
Ref. No. Part No. Part Name & Description Remarks
101 PQADGP0831GN LIQUID CRYSTAL DISPLAY S
102 PQAX2P07Z SPEAKER
103 PQBC10335Z1 BUTTON, NAVIGATOR KEY S
104 PQGT14558Z NAME PLATE (for KX-TG2583B)
104 PQGT14510Z NAME PLATE (for KX-TG2583S)
104 PQGT14647Z NAME PLATE (for KX-TG2583W)
105 PQHE10119Z CUSHION, URETHANE FORM
106 PQHG10620Z PACKING RUBBER, BATTERY
107 PQHG10621Z RINGER RUBBER
108 PQHG10630Z PACKING RUBBER
109 PQHR10727Z LCD PLATE
110 PQHR10739Z SPEAKER HOLDER
111 PQHR10850Z LCD HOLDER
112 PQHS10384Z PACKING SHEET, RINGER
113 PQHS10386Z PACKING SHEET, MIC
114 PQHS10461Z PACKING SHEET, SPEAKER
115 PQHS10484Z PACKING SHEET, EP CAP
116 PQHS10485Z CUSHION, SPEAKER
117 PQHX10862Z LCD COVER SHEET
118 PQHX10934Z SHEET
119 PQHX10959Z RF SPONGE
120 PQJT10175Z CHARGE TEMRINAL
121 PQKE10128Z1 EARPHONE CAP (for KX-TG2583B) (for KX-TG2583S) S
121 PQKE10128Z2 EARPHONE CAP (for KX-TG2583W) S
122 PQKE10129Z1 COVER (for KX-TG2583B) (for KX-TG2583S) S
122 PQKE10129Z2 COVER (for KX-TG2583W) S
123 PQP508SVC BATTERY S
124 PQQT22212Z CHARGE LABEL
125 PQSA10120Z ANTENNA (for KX-TG2583B) (for KX-TG2583S)
125 PQSA10120X ANTENNA (for KX-TG2583W)
126 PQSX10171Z RUBBER SWITCH (for KX-TG2583B) (for KX-TG2583S)
126 PQSX10171W RUBBER SWITCH (for KX-TG2583W)
127 PQYF10524Z1 REAR CABINET (for KX-TG2583B) S
127 PQYF10524Z2 REAR CABINET (for KX-TG2583S) S
127 PQYF10524Z4 REAR CABINET (for KX-TG2583W) S
128 PQYMTG2583BR FRONT CABINET ASS'Y (for KX-TG2583B)
128 PQYMTG2583SR FRONT CABINET ASS'Y (for KX-TG2583S)
128 PQYMTG2583WR FRONT CABINET ASS'Y (for KX-TG2583W)
23.2.2. MAIN P.C. BOARD PARTS
92
