105
3-8 Command for graphic data settings
3-8-1 Graphic file (VEC format file) : CDF
Sets the graphic file (VEC format) used for the graphic object.
⿎
Setting request data / response data for readout
Start
code
CDF
Sub
command
[Object No.] [Graphic file name]
Max. 256-byte
(Check
sum)
End code
Sub command is “S” for the setting request data and “A” for the response data for readout.
⿎
Readout request data
Start
code
CDF R
[Object No.]
2-byte
(Check
sum)
End code
⿎
Data description
Name
(> Name in LP-400/V)
Data length
[byte]
Data contents Remarks
Object No.
(> Logo No.)
2 “00”–“15”: Object No. 1200 to 1215
Graphic file name
Min. 1
Max. 254
The number of input characters
allowed: 5 to 127 characters
(including the extension “.VEC”)
Input Method: ASCII code or Shift
JIS code (can be mixed)
• The file extension “.VEC” can be
omitted.
• In the response data for readout the file
extension “.VEC” is included.
• Use the ASCII code to specify one-byte
characters (single byte characters).
• Use the Shift JIS code to specify
two-byte characters (double byte
characters).
• You cannot delete a graphic file (cannot
specify it with 0-byte).
Total data length Max. 256 Variable length.
ンㄆㄇㄆㄓㄆㄏㄆ
• Files configurable with this command are the graphic files (VEC format) saved in the laser marker.
• If the object type set in the specified object number is not the graphic (VEC), the laser marker returns the negative
response.
• This command cannot be used for other than VEC format graphic, such as DXF, BMP, JPEG or HPGL etc.
• Refer to “2-3-5 Character data input method” (P.37) for details on the character input method and character types with
input restrictions.
• Graphic file names are not case-sensitive.
• If the graphic file name contains both the one-byte characters and two-byte characters, specify them exactly as they are
in the ASCII code and the Shift JIS code.
• If the file name contains any characters which belong to the non-supported character code, the file cannot be selected
by the command.
⿎
Example of command settings
Condition: Object No. = 1, Graphic file name = Abcd.VEC
• Setting
Transmission data [STX] CDF S 01Abcd [CR]
• Readout
Transmission data [STX] CDF R 01 [CR]
Response data [STX] CDF A 01Abcd.VEC [CR]
To Next Page
