91
3-7-3 Bar code/2D code object settings: BRF
Sets the conditions such as the position and size of the bar code/2D code as well as code characteristics.
ンㄆㄇㄆㄓㄆㄏㄆ
• If the object type set in the specified object number is not the bar code/2D code, the laser marker returns the negative
response.
• To specify the module fill spacing of the bar codes, use WDC command (Line width / filling line spacing).
• The laser power correction and the scan speed correction set by this command will not apply to the human readable
text.
• With LP-400/V compatible command mode, you cannot set and readout the settings for PDF417, iQR code, QR code for
Chinese characters (GB/T 18284), and CODE93.
⿎
Setting request data / response data for readout
Start
code
BRF
Sub
command
[Object No.] [System reserved value]
[Code type] ... (vary depending on code type)
(Check
sum)
End code
Sub command is “S” for the setting request data and “A” for the response data for readout.
⿎
Readout request data
Start
code
BRF R
[Object No.]
1-byte or
2-byte (2D side of composite code)
(Check
sum)
End code
⿎
Data description
1. When the code type is CODE39/ITF/NW-7
Name
(> Name in LP-400/V)
Data length
[byte]
Data contents Remarks
Object No.
(> Bar code No.)
1 “0”–“7”: Object No. 1100 to 1107
System reserved
value
(Area No.)
1 “0”–“9”, “A”–“F”
This value does not affect the
settings anymore.
Code type 2
“00”: CODE39
“01”:ITF
“03”: NW-7
Invert 1
“0”: Do not invert
“1”: Invert
Set “0” to mark a bar, “1” to mark
a space.
Check character
(and Start/stop
character for NW-7)
1
For CODE39 and ITF
“0”: Check character OFF
“1”: Check character ON
• For CODE39 and ITF, specify
the existence of check
character.
• For NW-7, select start and stop
characters from A, B, C or D
and specify the existence of
check character.
For NW-7
“A”–“D”: Check character OFF
“a”–“d”: Check character ON
Bar code height 7
Model Setting range [mm]
LP-GS051(-L) “000.050”–“055.000”
LP-GS052 “000.050”–“030.000”
LP-RC350S “000.050”–“085.000”
LP-RF200P
LP-RV200P
“000.050”–“090.000”
To Next Page
